The Doggy Tourer dog bike trailer is E-bike compatible and can take up a maximum weight of 80kgs. 25-year warranty on aluminium parts.

Ride in the great outdoors with your furry best friend. The Doggy Tourer is incredibly durable and can withstand large loads and has individual wheel suspension ensuring a smooth ride on a trip to the shops in town or even on the rugged path to experience wonderful adventures together.

The trailer is waterproof, so come rain or shine outings are in, all year round. This lightweight dog trailer is easy to assemble and has quick-release fasteners to allow you to fold the trailer quickly. Handmade, produced, and manufactured in Germany, tailor designed for your companion. 25-year warranty on the aluminium parts and all products are non-toxic and of impeccable quality. Inside every Doggy Tourer, you will find a 7mm thick carpet that is almost indestructible. Your dog should be able to turn around in the trailer giving them freedom of movement.

Standard Equipment

Safety aluminum tube with maintenance-free elastomer springs

Aluminum double tube frame

16-inch wheels with 36 aluminum spokes

Weaver drawbar lockable, incl. 2 keys and safety belt with lashing clasp

7mm carpeting

3-in-1 hood with insect protection

waterproof up to a water column of 2500 mm

2x line attachment for DoggyTourer webbing (optional) in the interior

Pennant with pennant pole 80 cm

LED light according to StVZO

Reflectors front and back

Reflective bands in the side panels

parking brake on the left

The bicycle hitch is not included

Specifications

External dimensions unfolded: L 88 x W 80 x H 82 cm

Outer dimensions folded: L 88 x W 80 x H 22 cm

Empty weight: 11.3 kg (without accessories)

Permissible total weight: max. 80 kg

Interior: L 77 x W 50 x H 62 cm

The Shell

The shell of the Doggy Tourer bicycle trailer is made of flat and sturdy aluminum, which is scratch-resistant. A 3-in-1 hood protects the four-legged friend from rain, and you can always see your dog through the integrated windows. The suspension is designed for loads up to 80 kg.

The Frame

The frame of the bicycle trailers consists of an aluminium shell with a thickness of 1.5 mm. This tube is processed with a laser, cut, and the holes prefabricated. The tube is then placed on a double-tube aluminium frame and screwed. The corner connectors are made of glass fiber plastic now gives the substructure its strength and makes it possible to test the trailers with a load of 100 kg.

Elastomer suspension and a separate wheel suspension

Each bicycle trailer has an elastomer suspension and a separate wheel suspension. The 16 "wheels are cross-spoked 36 times and can withstand extreme loads. An industrial hub is used in the wheels with ball bearings.

Quick couplings make it easy to disassemble the wheels, after which the cart can be used as a bench.

Transforms into a stroller or Skater

The carts can also be equipped with an additional wheel at the front and thus converted into a buggy. You also have the choice between the Jogger/Skater set with a 16-inch wheel, so that the cart moves smoothly and can even be used for a walk on field and forest roads or when jogging or skating, or the Buggy set with the smaller Buggy wheel.

Aluminium Railings

The builders have gone to great lengths to make these carts exceptional.

The wheels can be dismantled easily by means of quick-release fasteners on the axles, after which the cart can be used as a doghouse. An aluminium railing can also be installed in the cart by means of an extension set so that it can serve as a real bench.
